Up to 6 cycles/minute

Application: Dedicated high-speed labeling lines (for example: retail can size production lines).

Features include:

  • All features of 600 MD
  • Pneumatic cylinders employed to retract UHMW Pattern Forming Bar and Pattern forming guides
  • Bi-directional conveyor belt drive
  • Bed length of 10’ long for accumulation
  • Scissors Lift with heavy duty pallet conveyor

Standard features of Intech Magnetic Palletizers/De-palletizers*:

  • Permanent Magnet Head with Pneumatic Stripper for the palletizer
  • Permanent Magnet Head for the de-palletizer
  • Bed: 10' long x 54"
  • Conveyor: up to 54” wide matt top belt
  • DEMAG rail style adjustable Carriage wheels
  • Electrical:
  • PLC Logic: Allen Bradley
  • All Control and electrical Panels are rated NEMA 12

Pallet up stacker and de-stacker
Heavy duty power conveyor for pallet staging up to 12 pallets high

Pallet conveyor:

  • 5’ Long Three (3) Chain conveyor
  • 5’ Long Power roll conveyor
  • 5’ Long 90-degree transfer conveyor

Sheet placer or Sheet remover:

  • Capable of automatically placing or removing sheets between each layer
  • Sheet Hopper
  • Sheet hopper with scissor lift
  • Extended bed length to 14’ long for additional accumulation
